TP-Link InSight PTZ5425 5-inch 4MP 25X Full-Color Network Speed Dome

Images are for illustration purposes only. Please refer to product description.

TP-Link InSight PTZ5425 5-inch 4MP 25X Full-Color Network Speed Dome

SKU: 608-1861 Categories: , , , , ,

Durable Performance in Harsh Outdoor Conditions

Add to Quote

Description

InSight PTZ5425

Get 360 monitoring and sharp close-ups with one single device. Slash deployment costs and complexity. Ideal for large-scale scenarios, such as parking lots, schools, farms, and construction sites.

  • 360° Wide-Area Coverage
  • 25X Optical Zoom & 16X Digital Optical Zoom
  • Intelligent Auto Tracking
  • Up to 240°/S Pan Speed
  • Red & Blue Flashing Lights and Sirens
  • People & Vehicle Attributes Analytics‡
  • Human & Vehicle Classification
  • Smart Detection
  • Smart Video Enhancement Technology
  • Audio and Alarm Interface Available
  • IP66 Weatherproof / K08 Vandal-Proof / 6kV Lightning Protecting
  • Digital Defog / Bulit-in Lens Heater
  • H.265+ Compression Technology

You may also like…

Related products

Create an Account.

Set up your QED account in minutes to access a wide range of products, 4pm order cut-off time, and a team that's always got your back.

Get Started
Manufacturer

Image Sensor

1/2.9” Progressive Scan CMOS
Minimum Illumination

0.005 Lux; 0 Lux with IR/White Light
Focal Length

5.2-130 mm (25X Optical Zoom)
FOV

• Horizontal FOV: 2.30°-57.06°
• Vertical FOV: 1.31°-32.74°
• Diagonal FOV: 2.63°-65.01
Pan/tilt Range

Pan: 0° to 360°, Tilt: -23.6° to 97.8°
Presets

300
Patrol Scan

8 patrols, up to 8 presets for each patrol
PTZ Protocol

Pelco-D, Pelco-P
Illuminator Type

• 2× IR LED
• 2× Integrated Infrared-White LED
IR LED

• Quantity: 2
• Range: 328 ft (100 m)†
• Wavelength: 850 nm
Video Compression

• Main Stream: H.265+/H.265/H.264+/H.264
• Sub-Stream: H.265/H.264
• Third-stream: H.265/H.264/MJPEG
Audio Communication

Two-Way Audio
Power Supply

DC
• 12V DC ± 5%, Max. 21.6 W, 5.5 mm Coaxial Power Plug
• Recommended Power Supply:

PoE
• PoE: 802.3at, Class 4, Max. 24.7 W

ErP Information
• Power consumption in networked standby when all wired network ports are connected and all wireless network ports are activated: 9.2W
Product Dimensions (L x W x H)

Φ6.3 × 10.6 in (Φ160 × 270 mm)
